Better Performance
the green way
Technology
• Vehicle Tracking System
• Rubber Dampers & Rare Shockers
Performance
• Safe Cabin
• Semless Handling
Trust
• 3+2 Years Warranty*
• CED Coated Paint
Power
• Switch Reluctant Motor (SRM) - 7.8 KW
• 12.6 KW LFP Battery Pack
Quality
• iCAT Approved
• 4 Terrain Tested
India's First 7+1 Seater 3 Wheeler EV Auto
Dabang MaxX offers 7+1 passengers carrying capacity and Bigger space.
Performance
Efficiency
Design
Safety
Saving
and last-mile connectivity
Charging Time
Full Charge in 5 Hrs
Technology
Front & Rear Suspension for smooth operations
Longer chassis
An upgraded wheelbase
Torque
80 Nm Torque
The Dabang MaxX has 7+1 passenger carrying capacity and a 150+ km* range, setting a new benchmark for last-mile and urban logistics in India.
shuttle services,
and city commutes
Join GEV World as a dealer! Open your EV showroom and drive the future of electric mobility with us.
The Dabang MaxX is a 7+1 Passenger EV Auto, is the best in its segment of 3-wheeler electric vehicles in India.
Dabang Ciy offers an leading range of 150+km* in a single charge.
L5 Cargo Model
Entrega LD
- 80 KM + Long Range
- Runs Like Thunder
- Result of 10+ Years of R & D
- 4+ Terrain Tested
SPECIFICATIONS
| MODEL | DABANG MAXX (PASSENGER) |
| VEHICLE COTEGARY | L5M |
| SEATING CAPACITY | 7+1 |
| VEHICLE DIAMENTION (LxWxH) | 3235 mm X 1540 mm X 1910 mm |
| WHEELBASE | 2200 mm |
| GRAUND CLEARENCE | 175mm |
| TURNING REDIOUS | 4.2 MTR |
| KERB VEHICLE WEIGHT (WITH BATTERY) | 544 kg |
| GROSS VEHICLE WEIGHT (WITH BATTERY) | 1244 kg |
| BATTERY | |
| MODEL | LFP 60V/210 AH |
| RATED VOLTAGE | 60.8V |
| BATTERY CAPACITY | 12.768 kwh |
| POWER TRAIN | |
| RATED WATT | 4000W |
| RATED VOLTS | 60v |
| RATED CURRENT | 77A |
| MAX CURRENT | 175A |
| MAX TORQUE | 80 Nm |
| PEAK POWER | 7.8 kW |
| TRANSMISSION | |
| TRANSMISSION TYPE | 10.2:1 THREE SPEED ELECTRINIC GEAR BOX |
| MAX. TORQUE ON WHEEL | 816 |
| SUSPENSION & BREAKS | |
| FRONT SUSPENSION | Hydraulic Telescopic Shock Absorber With Helical Compression Spring with dampener |
| REAR SUSPENSION | Hydraulic Telescopic Shock Absorber With Rubber Compression Spring with dampener |
| FRONT BREAK | HYDROULIC DRUM |
| REAR BREAK | HYDROULIC DRUM |
| STEERING | HANDLE BAR TYPE |
| TYER SIZE | 4.5-10, 8 PR |
| PERFORMENTION | |
| TOP SPEED | 44 -50 kmph |
| RANGE | 140 -165+ kms |
| GRADIENT | 22% |
| EXTERIOR | |
| ROOF TYPE | SOFT TOP |
| CHARGING | |
| HOME CHARGING | YES |
| CHARGING TIME | 4.3 hrs. |
